Main Machine

Rated Pressure

Mpa

28

28

28

Rated Flow

L/min

105

105

140

Rated Rotation Torque

N·m

4000

4500

6000

Rated Rotation Speed

r/ min

70-200

70-200

60-200

Feeding Force

kN

130

Feeding Speed （Fast/Slow）

mm/min

12/1.5

Pull-out Force

kN

190

Pull-out Speed （Fast/Slow）

mm/min

8/1.5

Feeding Stroke

mm

950

Pull-out Stroke

mm

950

Rotation Angle of the Rotary Base

（°）

0～360

Longitudinal Swing Angle of the Spindle

（°）

﹢90～90

Guide Rail Length

mm

1500±20

Minimum Horizontal Working Height

mm

1435±20

Maximum Horizontal Working Height

mm

2080±20

Pump Station

Rated Pressure

Mpa

28/22

Rated Flow

L/min

110

Motor Model

-

YBK3-280S-4

Rated Voltage

V

660/1140

Rated Power

kW

75

Effective Oil Tank Volume

L

230

Travel Mechanism

Travel Mode

-

Crawler Type Driven by Hydraulic Motor

Operating Pressure

Mpa

22

Operating Flow

L/min

100

Travel Speed

m/min

30

Gradeability

（°）

20

Overall   Dimensions

mm

4200×995×2390（±50）

Machine Weight

kg

5500
