Whloe Machine

Overall Dimensions in Operating State

mm

4000×1700×1800（±50）

Travel Pressure

Mpa

24

Travel Speed

m/min

20

Gradieability

。

20

Machine Weight

kg

10600

Ground Contact Pressure

Mpa

0. 079

Ground Clearance

mm

200

Noise Sound Power Level

dB（A）

87

Starting Current

A

1980/1030

Anti-pull-out Method of the Cable

—

Clip Type

Mud Pump

Rated Pressure

Mpa

0

50

Rated Flow

L/min

340

355

Number of Cylinders

-

5

Cylinder   Liner （Piston Plunger） Diameter

mm

50

Piston （Plunger）   Stroke

mm

100

Volumetric Efficiency

%

≥92

Total Efficiency

%

≥84

Hydraulic Pump   Station

Rated Operating Pressure

Mpa

25

Rated Operating Flow

L/min

100

Motor

Model

-

YBK3-225S-4

Rated Voltage

V

660/1140

Rated Current

A

40.1/23.2

Rated Current

kW

37

Rated Rotation Speed

r/min

1480

Driving Mud Pump   Motor

Model

-

YBRB-355S

Rated Voltage

V

660/1140

Rated Current

A

358.5/207

Rated Current

kW

355

Rated Rotation Speed

r/min

1498
